Simple Camera

This builds on the Simple Client by adding an interactive camera that supports orbiting, panning, and zooming. The render loop re-converges the image as the user moves the camera.

The example on this page can be tried directly using the link below. To build and run your own version, make sure you have the prerequisites in place.

Overview

The differences from the simple client are:

1. Create an AltAzimuthPerspectiveCamera and call copyFrom to initialize it from the scene camera
2. Listen for pointer and wheel events on the canvas to drive the camera
3. Each frame, call camera.update(), then renderer.copyCamera() to push the camera state to the renderer
4. The render loop restarts (if maxSamples has been reached) when the user interacts with the camera

Complete Example

Try Online

Step-by-Step

The canvas, imports, renderer, spec parsing, and scene loading steps are the same as the Simple Client. The differences start at creating the interactive camera.

Create the Interactive Camera

AltAzimuthPerspectiveCamera is a perspective camera that supports orbiting (altitude/azimuth rotation), panning, and zooming. Create one with the canvas dimensions, then call copyFrom to initialize it from the scene camera:

const camera = new Core.Cameras.AltAzimuthPerspectiveCamera({
  width:  canvas.width,
  height: canvas.height,
});
camera.copyFrom(scene.camera);

copyFrom copies position, orientation, and (for perspective cameras) fov, aperture, and focusDistance. It clones vectors internally, so you don't need to worry about shared references between the scene camera and the interactive camera.

Pointer and Wheel Input

AltAzimuthPerspectiveCamera exposes three manipulation methods:

Wire them up using standard pointer and wheel events:

let pointerDown = false;
let pointerButton = 0;
let lastX = 0;
let lastY = 0;

canvas.addEventListener('pointerdown', (e) => {
  pointerDown = true;
  pointerButton = e.button;
  lastX = e.clientX;
  lastY = e.clientY;
  canvas.setPointerCapture(e.pointerId);
});

canvas.addEventListener('pointermove', (e) => {
  if (!pointerDown) return;
  const dx = e.clientX - lastX;
  const dy = e.clientY - lastY;
  lastX = e.clientX;
  lastY = e.clientY;
  if (pointerButton === 2 || e.shiftKey) {
    camera.translate(dx, dy);
  } else {
    camera.rotate(dx, dy);
  }
  startLoop();
});

canvas.addEventListener('pointerup', () => { pointerDown = false; });
canvas.addEventListener('contextmenu', (e) => { if (running) e.preventDefault(); });

canvas.addEventListener('wheel', (e) => {
  e.preventDefault();
  camera.zoomWheel(e.deltaY, e.offsetX, e.offsetY);
  startLoop();
}, { passive: false });

setPointerCapture ensures drag events continue even when the pointer leaves the canvas. The contextmenu handler prevents the browser menu from appearing on right-click while the renderer is running; when stopped, right-click opens the browser menu (e.g. to save the image). Each interaction calls startLoop() to resume rendering if it has stopped.

Render Loop

Each frame, call camera.update() to apply pending manipulations, then call renderer.copyCamera() to push the camera state to the renderer:

const maxSamples = 1000;
let running = false;
let previousTime = performance.now();

function startLoop() {
  if (running) return;
  running = true;
  previousTime = performance.now();
  renderer.frameCount = 0;
  requestAnimationFrame(tick);
}

function tick(currentTime) {
  const elapsed = currentTime - previousTime;
  previousTime = currentTime;

  camera.update(elapsed);
  renderer.copyCamera(camera);

  renderer.updateAsync(elapsed);
  renderer.renderAsync(elapsed);

  if (renderer.frameCount < maxSamples) {
    requestAnimationFrame(tick);
  } else {
    running = false;
  }
}
startLoop();

The loop stops after maxSamples frames. When the user interacts with the camera, startLoop() resets the frame count and resumes rendering. Each camera move causes the image to re-converge from scratch.
