Z3

Z3 is a high-performance theorem prover developed at Microsoft Research. It is a built-in tool of GenAIScript. Z3 is used to solve logical formulas and can be used for various applications, including program verification, constraint solving, and symbolic execution.

GenAIScript uses the WebAssembly-based z3-solver npm package to run Z3.

Installation

npm i -D @genaiscript/plugin-z3

pnpm add -D @genaiscript/plugin-z3

yarn add -D @genaiscript/plugin-z3

If you are using the plugin in a Node.JS environment, without a .genai... entry file, you will need to initialize the runtime before using the plugin:

import { initialize } from "@genaiscript/runtime";

await initialize();

Z3 instance

The z3() method creates a new Z3 instance. The instance can be used to run Z3 commands and get the results. The z3 instance is a wrapper around the z3-solver npm package. The z3 instance has the run method that runs the given SMTLIB2 formula and returns the result.

import { z3 } from "@genaiscript/plugin-z3";

const z3 = await z3();
const res = await z3.run(`
(declare-const a Int)
(declare-fun f (Int Bool) Int)
(assert (< a 10))
(assert (< (f a true) 100))
(check-sat)
`);
console.log(res); // unsat

Z3 tool

The z3 tool plugin wraps Z3 as a LLM tool that can be used in GenAIScript. The tool takes a SMTLIB2 formula as input and returns the Z3 output.

import z3 from "@genaiscript/plugin-z3"

z3(env)

$`Solve the following problems using Z3:

(declare-const a Int)
(declare-fun f (Int Bool) Int)
(assert (< a 10))
(assert (< (f a true) 100))
(check-sat)

The tool won’t handle arbitrary problems, which takes us to the agent.

Z3 agent

The z3 agent (in system.agent-z3) script wraps the z3 tool with a LLM that can (try to) formalize arbitrary problems to SMTLIB2.

script({
  tools: ["agent_z3"],
});

$`Solve the following problems using Z3:

Imagine we have a number called 'a' that is smaller than 10.
We also have a special machine called 'f' that takes a number and a 'true'/'false' answer,
and it gives back another number.
When we put the number 'a' and the answer “true” into this machine,
the number it gives us is smaller than 100.`;
