Recipe: Command Palette¶

A command palette is a filter-as-you-type list with a keyboard accelerator to open and Enter to execute. In Microsoft.UI.Reactor (Reactor) it's three UseState hooks, a static catalog of Command records, and an OnPreviewKeyDown handler — no menubar, no modal manager, no view model. The palette is just another conditional overlay, layered over the page the same way the modal-dialog recipe layers its confirmation sheet.

Primitives¶

Concern	API
Open / query / selection state	`UseState<bool>` / `UseState<string>` / `UseState<int>`
Command catalog	`Command` records — same shape used by `Button`, `MenuItem`, `AppBarButton`
Filter	LINQ `Where(...Contains(query, OrdinalIgnoreCase))`
Open accelerator	`.OnKeyDown` on the root surface
List navigation	`.OnPreviewKeyDown` on the palette container
Overlay composition	`Group(page, palette)` — same shape as Recipe: Modal dialog

Command catalog¶

// The catalog is a static array of Reactor Command records. The same
// record could just as well be bound to a Button or a MenuItem — the
// palette is one more surface that consumes it.
private static readonly Command[] Catalog = new[]
{
    new Command { Label = "File: New",        Execute = () => Log("new") },
    new Command { Label = "File: Open…",      Execute = () => Log("open") },
    new Command { Label = "File: Save",       Execute = () => Log("save") },
    new Command { Label = "Edit: Find",       Execute = () => Log("find") },
    new Command { Label = "Edit: Replace",    Execute = () => Log("replace") },
    new Command { Label = "View: Toggle Theme", Execute = () => Log("theme") },
    new Command { Label = "View: Zen Mode",   Execute = () => Log("zen") },
    new Command { Label = "Go: Go to Line…",  Execute = () => Log("goto-line") },
    new Command { Label = "Go: Go to Symbol…",Execute = () => Log("goto-symbol") },
    new Command { Label = "Help: About",      Execute = () => Log("about") },
};

private static void Log(string id) { /* hook to telemetry in a real app */ }

A Command bundles a label with an action and metadata (commanding covers the full surface — icon, accelerator, CanExecute, async tracking). The palette only needs Label and Execute; the rest is there when you want to share the same record with a toolbar button or a context menu entry.

State¶

// Three pieces of state run the palette: whether it's open, the
// typed query, and the highlighted row in the filtered list.
var (open, setOpen) = UseState(false);
var (query, setQuery) = UseState("");
var (index, setIndex) = UseState(0);
var (last, setLast) = UseState<string?>(null);

Three hooks own the palette: open toggles the overlay, query drives the filter, and index is the highlighted row. A fourth last hook just echoes the most recently executed command for the demo — it's not part of the palette pattern.

Filter¶

// Re-derive the filtered list on every render. The catalog is
// small; a real palette with hundreds of commands would key this
// through UseMemo on `query`.
var matches = string.IsNullOrWhiteSpace(query)
    ? Catalog
    : Catalog.Where(c => c.Label.Contains(query,
        StringComparison.OrdinalIgnoreCase)).ToArray();
// Clamp the selection so it never points off the end of the list.
var safeIndex = matches.Length == 0
    ? 0
    : Math.Clamp(index, 0, matches.Length - 1);

The filter runs on every render. For a small catalog that's the right trade — no UseMemo ceremony, and the filter sees the latest query without an extra dependency array. Promote to UseMemo once the catalog crosses a few hundred entries or the predicate grows past Contains. The safeIndex clamp keeps the highlight valid when typing shortens the match list out from under the old selection.

Keyboard handler¶

// Esc closes; Up / Down move the selection; Enter invokes the
// highlighted command. The OnPreviewKeyDown handler intercepts
// before the TextBox gets the keystroke, so arrow keys move
// the list instead of the caret.
void OnPaletteKey(object _, Microsoft.UI.Xaml.Input.KeyRoutedEventArgs e)
{
    switch (e.Key)
    {
        case VirtualKey.Escape:
            setOpen(false);
            e.Handled = true;
            break;
        case VirtualKey.Down:
            if (matches.Length > 0)
                setIndex((safeIndex + 1) % matches.Length);
            e.Handled = true;
            break;
        case VirtualKey.Up:
            if (matches.Length > 0)
                setIndex((safeIndex - 1 + matches.Length) % matches.Length);
            e.Handled = true;
            break;
        case VirtualKey.Enter:
            if (matches.Length > 0)
            {
                var cmd = matches[safeIndex];
                cmd.Execute?.Invoke();
                setLast(cmd.Label);
                setOpen(false);
                setQuery("");
                setIndex(0);
            }
            e.Handled = true;
            break;
    }
}

OnPreviewKeyDown tunnels — it fires before the bubbling pair, so Up / Down move the selection instead of the TextBox caret, and Enter fires the highlighted command rather than inserting a newline. Setting e.Handled = true stops further routing so the underlying control stays out of the way. The same handler closes the palette on Escape; the input-and-gestures page covers the preview-vs-bubble pairing in detail.

Render¶

// The page is rendered normally; the palette is a conditional
// overlay on top, just like the modal-dialog recipe. The root
// surface owns the Ctrl+K accelerator so the palette can open
// from anywhere on the page.
var page = VStack(12,
    Heading("Command Palette Demo"),
    TextBlock("Press Ctrl+K to open the palette.").Opacity(0.7),
    last is null
        ? Empty()
        : TextBlock($"Last command: {last}").Opacity(0.6)
).Padding(24);

Element palette = Border(
    VStack(0,
        TextBox(query, v => { setQuery(v); setIndex(0); },
            placeholderText: "Type a command…").Width(420),
        matches.Length == 0
            ? TextBlock("No commands match.").Padding(12).Opacity(0.6)
            : VStack(0,
                matches.Select((c, i) =>
                    TextBlock(c.Label)
                        .Padding(10)
                        .Background(i == safeIndex ? "#E5F1FB" : "#FFFFFF")
                ).ToArray<Element>()
            )
    ).Background("#FFFFFF").CornerRadius(8).Width(440)
).Background("#80000000").Padding(60)
 .OnPreviewKeyDown(OnPaletteKey);

var root = (open ? Group(page, palette) : page)
    .OnKeyDown((_, e) =>
    {
        // Ctrl+K toggles the palette. A real app would prefer a
        // KeyboardAccelerator on the window root; this keeps the
        // recipe self-contained.
        var ctrl = (Microsoft.UI.Xaml.Window.Current?.CoreWindow
            .GetKeyState(VirtualKey.Control)
            & Windows.UI.Core.CoreVirtualKeyStates.Down)
            == Windows.UI.Core.CoreVirtualKeyStates.Down;
        if (ctrl && e.Key == VirtualKey.K)
        {
            setOpen(!open);
            e.Handled = true;
        }
    });
return root;

Command palette open with a filtered list

The page renders normally; the palette is a Border wrapping a VStack returned alongside it in a Group(page, palette). The scrim background #80000000 dims the page underneath. The root surface's .OnKeyDown watches for Ctrl+K and toggles open, which is the cheapest "global accelerator" that works from any focus state on the page.

For a real app, hoist the open accelerator to a window-level KeyboardAccelerator so the palette opens even when focus is inside a chart or a third-party control that swallows routed key events. The recipe keeps the handler inline so the composition is visible end-to-end.

Tips¶

The palette is not a modal. It's an overlay with an input that auto-focuses on open. Don't reach for UseFocusTrap unless your palette grows a help row, a settings flyout, or anything else that takes focus — for a single text field plus a result list, Esc-to-close is enough.

Bind to Command, not raw Action. Even though the palette only needs Label and Execute today, declaring the catalog as Command[] means the same record can drive a toolbar button or a menu item tomorrow without rewriting the catalog. The metadata travels with the action — that's the whole point of the commanding surface.

Refilter on every keystroke; memoize on every catalog. The filter is O(n) per keystroke; for the catalog sizes a command palette actually has (tens to low hundreds), a recompute on each render is well under a frame. Reach for UseMemo when the catalog grows or when the matcher does — a real fuzzy ranker deserves its own cache and is worth a separate recipe.

Reset on close. When the user dismisses, clear query and reset index to 0 so the next open starts fresh. The Enter handler in the recipe does both; the Esc branch can be tightened the same way if a stale query would surprise the user on the next open.
